FALCON'S CHEVALIER VERTICAL MACHINING CENTER


1418 VMC

THE MACHINE HAS FOLLOWING OUTSTANDING FEATURES

* The Control System is Fanuc 0i MB Package 'B' type.
* Linear Guide ways is provided for X, Y, & Z axes.
* The Axes Motor and the Ball Screws are directly coupled.
* MPG and Rigid Tapping are provided as standard.
* For all the 3 axes ball screws is of C-3 class pretension.
* Screw type Chip Conveyor is provided.
* Automatic Chip Flushing System is provided.
* Spindle is provided with 4 pieces of angular contact ball bearings and properly preloaded.
* Heat Exchanger for Electric Cabinet is provided.
* Fully enclosed Splash Guard is provided.

-------------------------------------------------------------------------------------------------------
